Description

Product details

Accuracy +/-5 DegreeC(at above 200 DegreeC upto 1250 DegreeC) Controller Type On/Off Control Brand YRK Power 100 to 240 VAC Type Digital Model Name/Number YRK-TC01 Display Type ALPHANUMERIC 2 LINE LCD Capacity 10 Amp potential free contacts(NO-C-NC) Control Action Automatic according to Set limits Control Output 1 No. Potential free contacts (NO-C-NC) Humidity upto 60%Rh Sensor Input K type thermocouple Display Size 16x2 Alphanumeric LCD Warranty 1 year against manufacturing defects. Material ABS plastic Din Enclouser(96x96x110mm) Color Black Event Function Set HIGH,LOW LIMIT,ALARM INDICATOR Communication Interface Rs232/Rs485 optional on custom request. Memory Backup yes Compatible Thermocouples K type Alarm Outputs No Dimension 96x96x110 mm Control Modes Digital Display Accuracy +-5 DegreeC Weight 230 grams Relay Output 10Amp No-C-Nc Display Method Digital Real Time Input Power Supply 120 - 220vAc No Of Alarm Modes 2(Hi & Low) Open Sensor Indication No. Operating Ambient Temp -10 to 70 DegreeC Operating Relative Humidity upto 65%RH Enclosure 96x96x120mm din type Sampling Rate 200m/s Sampling Time 1.5 seconds Set Point Independent for HIGH & LOW temperature Alarm Output Optional on custom request Maximum Distance To Sensor Depend upon cable size(upto 30mtrs @ 2.54mm ) Mounting Type Flush din type with bracket rod Response Time 1.5 seconds Cooling Method Natural Range 10-1250 DegreeC Sampling Cycle 200m/s Temperature controller reads upto 1250°C using with K type thermocouple. Independent temperature settings for High temperature Cut-Off and Low temperature Cut-On with memory. Display real time temperature with an accuracy of +- 5°C(above 200°C), also displays High and Low Set values. Display High/Low Alarm Indication. Potential free Relay output.
